| Imaging Device |
1/1.8″ 5MP CMOS x 4CH |
| Resolution |
2560×1920, 2560×1440, 1920×1080, 1600×1200, 1280×1024, 1280×960, 1280×720, 1024×768, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240 |
| Max. Framerate |
Max. 30fps/25fps (60Hz/50Hz) at all resolutions
Max. 30fps/25fps (60Hz/50Hz) |
| Min. Illumination |
Color: 0.11lux(F1.92, 30 IRE)
BW: 0Lux(IR LED on) |
| Lens |
| Focal Length (Zoom Ratio) |
4.13~9.4mm(2.3x)motorized varifocal |
| Max. Aperture Ratio |
F1.92(Wide)~F2.67(Tele) |
| Angular Field of View |
H: 87.58°(Wide)~37.34°(Tele) / V: 64.58°(Wide)~28.04°(Tele) / D: 112.46°(Wide)~46.85°(Tele) |
| Min. Object Distance |
1.2m(3.94ft) |
| Focus Control |
Simple focus |
| Lens Type |
DC auto iris |
| Pan / Tilt / Rotate |
| Pan / Tilt / Rotate Range |
Remote adjustment (Max. 200cycles)
0~360˚ / 35~80˚ / 0~90˚ |
| Operational |
| Camera Title |
Displayed up to 85 characters |
| Day & Night |
Auto(ICR) |
| Backlight Compensation |
BLC, HLC, WDR, SSDR |
| Wide Dynamic Range |
120dB |
| Digital Noise Reduction |
SSNRⅤ |
| Digital Image Stabilization |
Support |
| Defog |
Support |
| Motion Detection |
8ea, 8point polygonal zones |
| Privacy Masking |
32ea, 4point polygonal zones
– Color: Grey, Green, Red, Blue, Black, White
– Mosaic |
| Gain Control |
Low / Middle / High |
| White Balance |
ATW / AWC / Manual / Indoor / Outdoor |
| LDC |
Support |
| Electronic Shutter Speed |
Minimum / Maximum / Anti flicker (2~1/12,000sec) |
| Video Rotation |
Flip, Mirror |
| Analytics |
Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Audio detection |
| Alarm I/O |
Input 1ea / Output 1ea |
| Alarm Triggers |
Analytics, Network disconnect, Alarm input |
| Alarm events |
File upload via FTP and e-mail
Notification via e-mail
SD/SDHC/SDXC at event triggers
Alarm output
Handover |
| Audio In |
Selectable(mic in/line in)
Supply voltage: 2.5VDC(4mA), Input impedance: 2K Ohm |
| Audio Out |
Line out, Max.output level: 1Vrms |
| IR Viewable Length |
30m(98.43ft) |
| Network |
| Ethernet |
Metal shielded RJ-45(10/100/1000BASE-T) |
| Video Compression |
H.265/H.264: Main/Baseline/High, MJPEG |
| Audio Compression |
G.711 u-law /G.726
G.726(ADPCM) 8KHz, G.711 8KHz
G.726: 16Kbps, 24Kbps, 32Kbps, 40Kbps
AAC-LC: 48Kbps at 16KHz |
| Smart Codec |
Manual(5ea area), WiseStreamⅡ |
| Bitrate Control |
H.264/H.265: CBR or VBR
MJPEG: VBR |
| Streaming |
Unicast(20 users) / Multicast
Multiple streaming(Up to 10 profiles) |
| Protocol |
IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP |
| Security |
HTTPS(SSL) Login Authentication
Digest Login Authentication
IP Address Filtering
User access log
802.1X Authentication(EAP-TLS, EAP-LEAP) |
| Application Programming Interface |
ONVIF Profile S/T
SUNAPI(HTTP API)
Wisenet open platform |
| General |
| Webpage Language |
English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Swedish,, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek |
| Edge Storage |
Micro SD/SDHC/SDXC 4slot 256GB(each CH) |
| Memory |
5GB RAM, 1280MB Flash |
| Environmental & Electrical |
| Operating Temperature / Humidity |
-40°C~+55°C(-40°F~+131°F) / Less than 90% RH |
| Storage Temperature / Humidity |
-50°C~+60°C(-58°F~+140°F) / Less than 90% RH |
| Certification |
IP66, IK10, NEMA4X |
| Input Voltage |
HPoE(IEEE802.3bt, Class6, Type3), 12VDC |
| Power Consumption |
PoE: Max. 45 W, Typical 33.7 W
12VDC: Max. 42 W, Typical 32 W |
| Mechanical |
| Color / Material |
White / Aluminum |
| RAL Code |
RAL9003 |
| Product Dimensions / Weight |
Ø315×145.9 mm(12.40″x5.74″) / 5.2 kg(11.5lb) |
| Compatible Conduit hole / Gangbox |
3/4″ |
| Hanging Mount (Dome) |
SBP-317HMW |
| DORI (EN62676-4 standard) |
| Detect (25PPM/ 8PPF) |
Wide: 53.4m(175.2ft) / Tele: 151.5m(497.1ft) |
| Observe (63PPM/ 19PPF) |
Wide: 21.4m(70.1)ft) / Tele: 60.6m(198.9ft) |
| Recognize (125PPM/ 38PPF) |
Wide: 10.7m(35.0ft) / Tele: 30.3m(99.4ft) |
| Identify (250PPM/ 76PPF) |
Wide: 5.3m(17.5)ft) / Tele: 15.2m(49.7ft) |
